Main parameters:
| Wheel Drive | 4X4 |
| Engine Brand | YTO, XICHAI, LAIDONG |
| Dimension (L*W*D) (mm) | 3550*1450*2150 |
| R Wheel Tread (mm) | 960-1300 |
| Wheel Base (mm) | 1910 |
| PTO | 540/760 /1000 |
| Tyre Size | 650-16/11, 2-24, 750-16/12.4-24, 830-20/12.4-28, 280/70R20-380/85R24 |
1. Flat floor, 8+8 shuttle shift, side-mounted gear, convenient and flexible operation.
2. multiple gear selections, and strong adaptability.
3. Fully sealed front axle, with good sealing performance, preventing mud and wateringress, both flood and drought.
4. Achieve a narrow wheelbase, adjustable from 0.96-1.2 meters, and a wider range of adaptation.
5. Double clutch, separate operation of driving and power output, more suitable forsowing and receiving use.
6. Rear-mounted, central-mounted cylinder front axle, the left and right turning radius are the same, flexible and convenient.
7. Standard configuration with 2 sets of 2 way valves to meet the needs of differentegricultural machinery.
8. Optional air brake device to meet the needs of road transportation.
For more details and prices, please contact us!
